7-1-3 Modbus Communication Protocol for RS-485
The MODBUS protocol allows an easy communication within types of network architectures,before start to
communication with slave device, set the ID number ( Cn036 ) for Servo drive respectively, server distinguish ID
number for controlling specific client station.
Standard Modbus networks combine two transmission modes: ASCII or RTU: ASCII(American Standard Code
for information interchange) Mode and RTU (Remote Terminal Unit) Mode, Use Cn038 to select ASCII or RTU
mode.
Coding method
ASCII Mode
8-bits Data consist of two ASCII code.
Ex: Data 26H 1-byte , the ’26’ convert to ASCII code is include character ’2‘ <32H> and ’6’ <36H>
ASCII Chart ( 0 ~ 9 and A ~ F ):
Character ‘0’ ‘1’ ‘2’ ‘3’ ‘4’ ‘5’ ‘6’ ‘7’
ASCII code(Hex) 30H 31H 32H 33H 34H 35H 36H 37H
Character ‘8’ ‘9’ ‘A’ ‘B’ ‘C’ ‘D’ ‘E’ ‘F’
ASCII code(Hex) 38H 39H 41H 42H 43H 44H 45H 46H
RTU Mode
Each 8bits is consist of 2 Hex number (4-bits per Hex number).
Ex.: Data 26H, the data length is 1-byte.
