※Standard Specifications for JSMA-PHH (200V Class)
JSMA-P□□□□
Motor Mode Symbol Unit
HH30A HH44A HH55A HH75A
Drive Model
100A3 150A3 200A3 300A3
Rated Output P
R
KW
3.00 4.40 5.50 7.50
Rated Torque T
R
N．m
19.10 28.00 35.10 47.80
Max. Torque T
max
N．m
49.50 71.40 89.60 122.60
Rated Speed N
R
rpm
1500
Max. Speed N
max
rpm
3000
Rated Current I
R
A
23.00 33.20 42.10 58.00
Max. Armature
Current
I
max
A
59.80 86.30 109.50 151.00
Torque Constant K
T
N．m/A
0.83 0.84 0.83 0.82
Rotor Moment of
Inertia
J
M
Kg．cm
2
39.99 53.02 63.52 93.94
Armature Resistor Ra Ω
0.08 0.05 0.04 0.02
Armature Inductance La mH
1.48 0.89 0.68 0.43
Mechanical Time
Constant
Tm ms
0.70 0.62 0.56 0.51
Electrical Time
Constant
Te ms
18.75 16.54 17.46 18.00
Weight(Standard) W kgw
19.5 26.2 30.0 42.0
Insulation Grade ─ ─
Class F (155℃)
Operating Ambient
Temp.
T
℃
0 ~ 40
Operating Ambient
Humidity
RH %
<90
Storage Temp. T
℃
-20 ~ 60
Storage Humidity RH %
<90
1( kgf‧cm)＝0.0980665(N‧m) ； 1(gf‧cm‧s
2
)＝0.980665(kg‧cm
2
)
