1-1-2 Servo Motors Model Designation
JSM A – S C 30 A H K B
Warning
Make sure parameter CN030 is setting correctly before start operate this drive.
Setting method reference 1-1-3 .
Encode
Spline
Grease Seal

No No
K Yes No
O No Yes
A Ye s Yes
TECO AC Servo
Motor No.
Motor Series:
Series A
Motor inertia:
S/T: Extra low
L: Low
M: Middle
Motor Speed:
A: 1000 rpm
B: 2000 rpm
C: 3000 rpm
H: 1500 rpm
Encolder:
F: 2000 ppr
B : 2500 ppr
H : 8192 ppr
Motor rate power
P5 : 50 W
01 : 100 W
02 : 200 W
03 : 300 W
04 :400W
05 : 550W
08 : 750W
10 : 1 KW
15 : 1.5 KW
20 : 2 KW
30 : 3 KW
AC input voltage
A
：
AC 220V
M:
Machinery BK
 : No BK
B:Mech. brake
!
