TECO JSDE-15 User Manual

7
1-1-3 Servo motor Model Code display
dn-08 (Servo motor Model Code display)
Use dn-08 to display servo motor code and find Cn030 setting code for your servo drive and motor according to table
list below. If the dn08 code is not list below then contact to area distributor.
Ex. JSDE-15 servo drive with JSMA-SC02AF motor the setting code of Cn030 is [H0130].
Motor Standards
dn-08 Display
Cn030 Setting
Drives Model Motor Model
Watt
(W)
Speed
(rpm)
Encoder
Specification
H1011 JSMA-SCP5AB 50 3000 2500
H1021 JSMA-SC01AB 100 3000 2500
H0030 JSMA-SC02AF 2000
H1043
JSDE-10
JSMA-TC02AB
200 3000
2500
H0121 JSMA-LC03AB 300 3000 2500
H0130 JSMA-SC02AF 2000
H1133 JSMA-TC02AB
200 3000
2500
H0140 JSMA-SC04AF 2000
H1141 JSMA-SC04AB 2500
H1143
JSDE-15
JSMA-TC04AB
400 3000
2500
H0211 JSMA-LC08AB 750 3000 2500
H0220 JSMA-SC04AF 2000
H1221 JSMA-SC04AB 2500
H1223 JSMA-TC04AB
400 3000
2500
H0230 JSMA-SC08AF 2000
H1233 JSMA-TC08AB
750 3000
2500
H0241 JSMA-MA05AB 1000 2500
H0251
JSDE-20
JSMA-MH05AB
550
1500 2500
H0310 JSMA-SC08AF 2000
H1313 JSMA-TC08AB
750 3000
2500
H0321 JSMA-MA10AB 1000 2500
H0331 JSMA-MB10AB 2000 2500
H0341 JSMA-MH10AB 1500 2500
H0351
JSDE-30
JSMA-MC10AB
1000
3000 2500
