Note: On readers with dual LED control lines, LED 2 may also be programmed to
indicate other conditions via the NAC’s macro logic programming.
Format
Select the card format for the reader from the following options:
Tecom 27 bit – For range of Tecom proximity readers supplied by UTC
Fire & Security.
Wiegand 26 bit – For standard 26-bit Wiegand format readers. Has a 16-
bit card number (0-65534) and an 8-bit site code (0-255).
Reader
Program the reader’s location using the scheme described in the “Flexible device
locations” section on page 18.
Enabled
Tick the check box to enable the reader.
LCD fitted
Tick the check box if the reader has LCD (liquid crystal display).
Enable egress
Tick the check box if the reader has an egress button connected to the reader’s
IN or EGRESS terminal.
Door reader dialog – LED mapping tab
The LED mapping tab allows the operator to program which area number is
assigned to the reader’s area LEDs, if applicable.
Note: LED mapping does not apply to the NAC in IP Direct mode.
