Tecsun PL-310ET - Page 2

PL-310ET Functional Block Diagram
PL-310ET is using DSP si4734 Microchips (from Silicon Labs in
USA) to digitalize the analog AM/FM broadcasting signal base
on the modern software technology and radio principles. It can
highly improve on radio's sensitivity, selectivity, S/N ratio and
anti-interference.
AMPLIFIER
CONTROLLER
CONTROL
INTERFACE
SW LPF
FM ANT
MW/LW ANT
PL-310ET
Functional Block Diagram
MEMO
