3.2. Overview Mistral (Eco) (Super) Plus
Illustration 1: Total view
Pos.1 Transparent announcement, transparency keyboard Pos.10 Filter unit
Pos.2 Covering Pos.11 Activated carbon
Pos.3 Filter casing Pos.12 Tension close device
Pos.4 Activated carbon casing Pos.13 2x Extraction tube NW50
Pos.5 Turbine casing Pos.14 Extraction tube NW71
Pos.6 Guiding roller Pos.15 Exit grille
Pos.7 Guiding roller with brake Pos.16 Sub-D9 connection
Pos.8 Handle Pos.17 Mains connection
Pos.9 Frame (empty)
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 16 of 47
