Program and Version number: Display of programs and versions-No. e.g. Mistral 3.01
Pass-code: Announcement Code 10
Indicates the number entered last.
The following entries may be made with the pass-code (for servicing personnel only):
Differential-pressure filter: Announcement „filter 2000 Pa“. Maximum filter-load setting in
Pascal.
This corresponds to 100% of the filter saturation display.
Pre-set data: 2000 Pa.
Maintenance-interval activated carbon: Announcement: „coal time: 1000h“. Pre-set data for the
maintenance-interval indicated in hours.
Maintenance-interval brushes: Announcement: „brushes no“. Indicates whether the
maintenance-interval is activated.
The maintenance-interval for the brushes (450 hours) is pre-set
fix and can not be changed.
Pressure sensor reset: Announcement adjust? 0000 Pa
The display shows the current pressure (in Pa) on the clean air
side.
The pressure sensors can be activated by pressing the button „+“.
While the adjustment is being carried out the turbine (s) is switched
off.
The display shows a countdown from 20 sec. after 20 sec, the
pressure sensors are adjusted (reset) and „OK“ is displayed. The
basic announcement appears once more when the function is
concluded.
Confirmation with the „+“ or „-“ button allows the turbine (s) to be
re-activated.
Attention: In order to receive correct results of measurement, the pressure sensor should be reset at least
every 6 month. Reset the pressure sensor also when the announcement indicates illogical results or with
error tracing.
6.6. Remote Control
Apart from the operation with the transparency keyboard there is still additionally the possibility to control the
Mistral about a wireless remote control or over a lead to an external control console (e.g. at the machine
which can be exhausted).
Depending upon execution of the remote control all or only one part of the functions described in the previous
section can be implemented.
Attach the external control console with a shielded cable at the Sub-D9-plug at the turbine case of the Mistral
Consider the references in the section 5.1.
Reference!
If you switch off the Mistral externally via the remote control, the turbines run after (the pre-set time of 10
seconds) and switch off only then.
This delay ensures that a majority of the gas/smoke are sucked off.
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 27 of 47
