Teka Mistral Plus - Mistral Plus, Mistral Eco Plus and Mistral Super Plus; Differential Pressure

3.6.2. Mistral Plus, Mistral Eco Plus and Mistral Super Plus
Filtering device: Mistral Plus, Mistral ECO Plus, Mistral Super Plus
Housing: Breadth 365 mm
Width 1240 mm
Dept 681 mm
Surrounding: Surrounding temperature, perm. + 5 °C bis + 35 °C
Relative air humidity max. 65 %
Data
Mistral Plus 230: Maximum air flow 280 m
3
/h
Power of the motor 1,1 kW
Connection voltage 230 V / 50/60Hz
Maximum negative pressure 21000 Pa
Mistral Eco Plus 230: Maximum air flow 330 m
3
/h
Power of the motor 1,2 kW
Connection voltage 230 V / 50/60 Hz
Maximum negative pressure 14.000 Pa
Mistral Plus 110: Maximum air flow 280 m
3
/h
Power of the motor 1,2 kW
Connection voltage 110 V / 50/60 Hz
Maximum negative pressure 21.000 Pa
Mistral Eco Plus 110: Maximum air flow 330 m
3
/h
Power of the motor 1,2 kW
Connection voltage 110 V / 50/60 Hz
Maximum negative pressure 14.000 Pa
Mistral Eco Super Plus 230: Maximum air flow 640 m
3
/h
Power of the motor 2,4 kW
Connection voltage 230 V / 50/60 Hz
Maximum negative pressure 14.000 Pa
Mistral Eco Super Plus 110: Maximum air flow 640 m
3
/h
Power of the motor 2,4 kW
Connection voltage 110 V / 50/60 Hz
Maximum negative pressure 14.000 Pa
Filter material
Filter-unit:
Activated carbon:
Pre-filter mat for activated carbon:
Filter classification F 9
27 kg
Filter classification G4
3.7. Differential pressure
Unit Pa
Mistral with 1 turbine
Mistral with 1 turbine and the PreFilter
Mistral with two turbines
Mistral with two turbines and the PreFilter
2500
3500
3200
5000
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 19 of 47
