Teknoware TKT66 - Control Module panel test functions and alarms

VOT1; Rev 1.5; EN; 5.11.2015
TKT66 – Installation and maintenance
21
4.10 Control Module panel test functions and alarms
LED
Description
Instruction
BATTERY TEST
As a basic setting, the battery test is done
automatically twice a year: on the 4
th
of July
and on the 4
th
of January, at 12 pm (midnight).
 If the LED is continuously lit, the battery
test is in progress.
 If the LED is flashing, an error has been
detected in the battery test. In this case
the External fault LED will also be lit.
During the battery duration test, the central
battery unit is switched to battery mode and
all output circuits are switched on.
 If the LEDs Internal fault is lit and Battery
test is flashing, the battery duration test
has failed.
A change of battery always requires a new
configuration, so that the software knows a
battery has been replaced.
The battery test can be started by pressing
one button on the control unit interface, or
manually using the control unit menu.
No action needed, unless the test
fails. If the test fails check condition
of batteries
To run the battery test yourself,
either
1. Press the BROWSE button for
8 seconds.
or
1. Press the MENU / OK button.
2. Use the BROWSE button to
select 2, TESTING.
3. Use the SET button to select 3,
battery test during 2/3 of the
operation time.
4. Accept the selection with the
MENU / OK button.
The battery test starts.
LUMINAIRE TEST
If the LED is continuously lit, the luminaire test
is in progress.
If the LED is flashing with External fault LED,
configuration is in progress.
Luminaire test must be carried out once in 1-7
days. Factory setting is once a day at
midnight (00.00 o’clock).
No action needed, unless the test
fails. If the test fails check condition
of luminaires.
To run the luminaire test yourself,
either
1. Press the BROWSE button for
3 seconds.
or
1. Press the MENU / OK button.
2. Use the BROWSE button to
select 2, TESTING.
3. Use the SET button to select 1 =
Starting the luminaire test.
4. Accept the selection with the
MENU / OK button.
The luminaire test starts. If a faulty
luminaire was found in any of the
circuits, its corresponding LED will
