TKT66 – Installation and maintenance
7
The central battery unit does not require any other regular user action after its installation and
commissioning than checking the status of the signal LEDs (the left-hand side bar) at specified
intervals.
No separate data transfer cables are needed for the luminaires as the data is transferred via the power
supply cables.
A self-learning system; luminaires can be added or removed afterwards.
The central battery unit can be set for either addressable monitoring of the luminaires or for circuit
monitoring. In the addressable monitoring of the luminaires, the luminaires must be equipped with an
address module from Teknoware. All the Teknoware luminaires the type code of which ends in letter K
are fitted with this feature.
The batteries Pb (18 pcs) or NiCd (180 pcs) for the central battery unit always require a separate
battery container and battery cables.
All the functions related to the use of the central battery unit can be performed using its control panel
that also includes display LEDs to indicate the status of the unit. The panel functions are described in
Chapter 4.6 , Operation of the central battery unit.
3.7 Technical specifications
Mains connection:
220-240 VAC 50-60 Hz 1~, or F-models N/PE 220-240 VAC
50/60 Hz 3~
Casing:
TKT66xxCxx: IP20
TKT66xxCPxx (cabinet construction): IP34
Output voltage:
mains connection: 220-240 VAC, battery operation: 216VDC
Battery voltage:
216 VDC
Battery charging time:
12 h 80 %
Max. batteries:
18 x 65 Ah
Input power
TKT6608C(N)(P)xxx:
3680 VA
Max Input power
TKT6608CF(P)xxx:
3900 VA
Max Input power
TKT6616C(N)(P):xxx
3680 VA
Max Input power
TKT6616CF(P)xxx:
6700 VA
Max Input power
TKT6624C(N)(P)xxx:
3680VA
Max Input power
TKT6624CF(P)xxx:
7100 VA
Ambient temperature range:
+10 – 50C
Input fuse:
1-phase circuit breaker 16 A C curve or in F-models 3-phase
16 A C-curve
Output circuit fuses:
5x20 mm sand-filled glass tube fuse 2,5 A
Output connector:
max. wire 4 mm
2
Required short-circuit
current with 2.5 A fuse 0,4 s.
tripping time:
10 A
Battery Fuse
TKT6608C(P)xxx:
2x35 A plug fuse S 35 A/250 V Neozed
Battery Fuse
TKT6616C(P)xxx:
2x35 A plug fuse S 35 A/250 V Neozed
Battery Fuse
TKT6624C(P)xxx:
2x35 A plug fuse S 35 A/250 V Neozed
Charging circuit fuses:
5x20 mm glass tube fuse 6,3 A
Backup battery for CBU
settings
Battery type: Teknoware XWT9001
Operation time: min. 12 hrs (with 48 hours of recharge)
