TKT66 – Installation and maintenance
35
The log shows the date, time and duration of the test, as well as the voltage of the battery set at the end
of the test. To move back to the higher-level menu from the test log, press the SETUP button for 1.5 s.
Figure 8. Luminaire test log
8.1.6 Error log
In addition to the log of the luminaires and battery tests, the display shows an error log of all errors
detected in the central battery system. The log shows the date and time of each error, as well as a
corresponding error code. If you want to view the data for a particular log, first select the desired log
using the +/- buttons, then confirm your selection by pressing the SETUP button. To move back to the
higher-level menu from the test log, press the SETUP button for 1.5 s.
Figure 9. Error log
Error code: Error description:
1 Internal error
2 External error
3 Central battery system has not been configured
4 Internal and external error
5 Fuse fault or other malfunction in output circuit
6 Deep discharge
7 Error with changeover board
8 Overload
To move back to the higher-level menu from the test log, press the SETUP button.
8.1.7 Setup
You can change the settings and start tests by first selecting the desired function using the +/- buttons
and then confirming your selection by pressing the SETUP button. Using the Setup display, you can
start a battery or luminaire test, as well as set the date and time. Once you have started a battery test,
you can cancel it by pressing the SETUP button and then selecting Stop battery test.
You can start a luminaire test by selecting Start luminaire test. The first luminaire test will configure the
central battery system.
You can set the date and time by selecting Set date and time. In the clock settings, a blinking cursor
identifies a value that you can change with the +/- button. You can change the parameter whose value
you want to change by using the SETUP button. Once you have set the date and time, you can leave
the menu by pressing the SETUP button, after which the new settings will be stored in the central
battery system in a matter of few seconds.
To move back to the higher-level menu from the test log, press the SETUP button for 1.5 s.
Date Time Log
23.03.11 10:30 Error
Battery test duration 01:25
Battery set voltage 221V
Browse luminaire tests
Browse battery tests
Browse error log
Setup
Date Time Error
>23.03.11 10:30 2
23.03.11 10:32 5
22.03.11 00:15 2
