Teknoware TKT66 - Parts layout

VOT1; Rev 1.5; EN; 5.11.2015
TKT66 – Installation and maintenance
26
5.2.1 Parts layout
Dip switches for
XST2618 and XST0201
Mode links
Battery fuses F2 and F3
Distribution fuse F1
or F1, L1-L3 in F models
Connectors X1-
3 and fuses F1-
F24
