APPENDIX 1: Report Layout
Title information
CENTRAL BATTERY UNIT 01
00.00.2010 00:00
CIRC. LUMINAIRE MONITORING A B C D mA
The input current of the circuit
01-Lo OOOO OOOO OO.. .... _ _ _ _ 360
02-Lo OOOO OOOO OO.. .... _ _ _ _ 380
03-Lo OOOO OOOO OO.. .... _ _ _ _ 390
04/Lo .O.. .... .... .... _ _ _ _ 320
\Hi ..OO OOOO OO.. ....
05-Lo OOOO OO.. .... .... _ _ _ _ 470
06-Lo .OOO OO.. .... .... _ _ _ _ 400
07-Lo OOOO OO.. .... .... _ _ _ _ 430
08-Lo OOOO OO.. .... .... _ _ _ _ 440
CIRC. CIRCUIT MONITORING A B C D mA
09-P- ...O OOOO OOOO OOOO _ _ _ _ 360
10-P- ...O OOOO OOOO OOOO _ _ _ _ 380
11-P- ..OO OOOO OOOO OOOO _ _ _ _ 390
12-P- .... .OOO OOOO OOOO _ _ _ _ 310
13-P- OOOO OOOO OOOO OOOO _ _ _ _ 460
14-P- ..OO OOOO OOOO OOOO _ _ _ _ 390
15-P- .OOO OOOO OOOO OOOO _ _ _ _ 420
16-P- .OOO OOOO OOOO OOOO _ _ _ _ 420
Lo = addresses 1-16
Hi = addresses 17-32
P = Circuit monitoring
In circuit monitoring the strength of the current
is shown from right to left
DISCHARGE CURR. 01.20A
 Current of all circuits in battery use
BATT. VOLTAGE 249V
 Voltage of battery on time of printing
LUMINAIRE TEST OK 00.00.00
 Result and date of last luminaire test
BATTERY TEST OK 00min 00.00.00
 Result and date of last battery test
SYSTEM TEST OK
 Fault in central module, battery or charging
circuit
SETTING
Auto conf 1 A=Local Contr.1
 Automatic configuration ON
Test Selection 1/1 B=Overload
 Test Selection 1/1 = Gap between test
dates / selected automatic tests
Sensitivity 080mA C=Fuse
 Current-range of circuit monitoring
Test Duration 24:00 D=Output Switch
 Selected time of day for luminaire test
Connect. Delay 00min O=OK
 Selected connection delay from battery use
to mains use
Battery Level 210V #=Faulty
 Voltage with which automatic battery test
will be stopped
Operation time 060min
 Operation time of the central battery unit
STATUS 110800emd
 Status message tells the status of the unit
Symbol explanations:
A= Local Controller Fault
O = OK
B= Circuit Overload
# = fault
C= Fuse Fault
D= Output Circuit Fault
? =Unknown luminaire (added, automatic
configuration not in use
 = Luminaire not connected
