Teknoware TKT66 - External USB Connection

VOT1; Rev 1.5; EN; 5.11.2015
TKT66 – Installation and maintenance
36
NOTE: A battery test cannot be started unless the battery set is sufficiently charged.
Figure 10. Settings and starting a test
8.1.8 External USB connection
A USB port on the LCD allows data entered in a separate PC programme to be transferred to the LCD.
Using the PC programme, luminaires can be given names, along with descriptive information. Connect
the LCD to the PC using a USB cable. Once you have connected the cable to the LCD, the following
display is shown:
Figure 11. USB cable connected
The LCD software will scan the USB ports, opening a connection. A new row will appear on the display,
informing you that a connection has been opened. The connection is now open.
Figure 12. Connection opened
The buttons on the LCD cannot be used if there is an active USB connection between the LCD and the
PC. For more information, please refer to the PC programme user's guide.
Browse luminaire tests
Browse battery tests
Browse error log
Setup
Start battery test
Start luminaire test
Set date and time
Stop battery test
Start luminaire test
Set date and time
PC connected
Data transfer speed 1200
PC connected
Data transfer speed 1200
Connection opened
