Performance Check—2465B/2467B Service
Table 4-1 (cont)
Item and
Description
16. Attenuator
17. Attenuator
18. Attenuator
19. Digital Multimeter
(DMM)
20. Low-Capacitance
Alignment Tool
21. 1X Probe
22. Normalizer
23. Tunnel Diode Pulser
24. Pulse Generator (2
required)
25. Adapter (2 required)
26. Adapter
Minimum Specification
Attenuation factor: 2X. Impedance: 50 n.
Connectors: BNC.
Attenuation factor: 5X. Impedance: 50 fi.
Connectors: BNC.
Attenuation factor: 10X. Impedance:
50 Q. Connectors: BNC.
DC volts range to +20 V. Accuracy:
±0.2%.
Shaft length: 2 in.
Attenuation: 1X. Bandpass: <20 MHz.
Input resistance: 1 MIL Input
capacitance: 15 pf.
Rise time: 125 ps or less.
Frequency: 10 MHz. Pulse width: 50 ns.
Pulse width accuracy: 5%. Positive
trigger input, 1 V to 5 V into 50 Ohms.
Positive trigger output, 1 V into 50 Ohms.
Variable pulse duration.
Connectors: BNC male-to-dual-binding.
BNC-to-probe-tip.
Use
Signal attenuation.
Signal attenuation.
Signal attenuation.
Check power supplies
and CALIBRATOR.
Adjust variable resistors
and capacitors.
Check power supply
ripple.
Check input
capacitance.
Check transient
response.
CTT Checks.
CTT Checks.
Signal inter-connection.
Example of Applica-
ble Test Equipment
TEKTRONIX Part
Number 011-0069-02.
TEKTRONIX Part
Number 011-0060-02.
TEKTRONIX Part
Number 011-0059-02.
TEKTRONIX DM 502A.
TEKTRONIX Part
Number 003-0675-00.
TEKTRONIX P6101-01.
TEKTRONIX Part
Number 067-0537-00.
TEKTRONIX Part
Number 067-0681-01.
TEKTRONIX PG502
Pulse Generator.
TEKTRONIX Part
Number 103-0035-00.
TEKTRONIX Part
Number 013-0227-00.
