Tektronix 3 Series Service Manual

Table 6: Rear case
Index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
Figure 8: Rear case exploded view on page 24
-1 211-1688-XX 4 SCREW, MACHINE, M3X0.5X10, FLAT HEAD 90 DEG, SUS410 NYLOK,
TORX T10
-2 065-1060-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT HANDLE ASSEMBLY
-3 065-1059-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT HANDLE HUB
ASSEMBLY, RIGHT AND LEFT
-4 378-0963-XX 1 GRILLE, COSMETIC, REAR
-5 211-1686-XX 10 SCREW, MACHINE, M3X0.5X10 FLAT HEAD, STL, TORX 10
-6 065-1047-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT; REAR FLIP FEET; 3 & 4
SERIES (QTY 2 IDENTICAL)
-7 202-0579-XX 1 CASE, REAR, ASSEMBLY. INCLUDES: PLASTIC CASE, PLASTIC TRIM,
and WRAP LABELS
Replaceable parts
3 Series MDO Mixed Domain Oscilloscope Service Manual 25
