Tektronix 3 Series Service Manual

Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
-5 253-0594-XX 1
TAPE, CONDUCTIVE, LINE FILTER SHIELD
If the tape is removed during service, replace it during reassembly.
The tape is removed during 119-7086-xx (#8) and 174-6286-xx (#9)
replacement.
-6 211-1686-XX 2
SCREW, MACHINE; M3X0.5X10, FLAT HEAD, STL, TORX 10
-7 335-4064-XX 1 LABEL, REAR I/O
-8 119-7086-XX 1 FILTER, EMI; AC LINE CONNECTOR/INPUT FILTER;6.0 A, 120-250
VAC, DC-400 HZ, 2.2 NF CY, 100 NF CX, IEC INPUT, FAST-ON/SOLDER
LUG OUTPUT, CHASSIS MOUNT, SAFETY CONTROLLED
-9 174-6286-XX 1
CABLE ASSEMBLY (LINE INPUT), SAFETY CONTROLLED
-10 174-6284-XX 1
CABLE, POWER SUPPLY, OUTPUT
-11 119-8042-XX 1 POWER SUPPLY; AC-DC; 90-264 VAC 45-66 HZ, 100-132 VAC 360-440
HZ IN; +12 V@12 A5, +5 V@1 A, 150 W, OUT; PS_ON#, PWR_GOOD
SIGNALS; SAFETY CONTROLLED
-12 211-1584-XX 32
SCREW, MACHINE, M3X0.5X6MM PAN HEAD, TORX T10
-13 878-1624-XX 1 ASSEMBLY, CIRCUIT BOARD, I/O BOARD
Replaceable parts
3 Series MDO Mixed Domain Oscilloscope Service Manual 27
