Tektronix 3 Series Service Manual

Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
-4 133-0194-XX 2 CONTACT, SPRING FRONTPANEL, LED BOARD TO CHASSIS,
INSTALLED ON SPACER
-5 211-1585-XX 3
SCREW, DELTA-PT, 3MM X 8MM, T10
-6 133-0192-XX 3
CONTACT, SPRING FRONT PANEL
-7 878-1622-XX 1 ASSEMBLY, CIRCUIT BOARD, PROBE INTERFACE
Return the instrument to Tektronix for service.
-8 878-1620-XX 1 ASSEMBLY, CIRCUIT BOARD, FRONT PANEL ENCODER
Return the instrument to Tektronix for service.
-9 380-1331-XX 1 HOUSING, PROBE COMP
Return the instrument to Tektronix for service.
-10 131-9410-XX 1
CONNECTOR,RECEPTACLE,GROUND JACK
-11 361-1892-XX 1 SPACER, FRONT PANEL
Return the instrument to Tektronix for service.
-12 065-1038-XX 1
MODULE ASSY:SERVICE REPLACEMENT KIT;FRONT PANEL DOME
SWITCH ARRAY, AND PCBA, FRONT PANEL-SWITCH/LED, MDO32
AND MDO34
Return the instrument to Tektronix for service.
-13 260-3116-XX 1 EMAT, FRONT PANEL
Return the instrument to Tektronix for service.
-14 335-4091-XX 1 LABEL, BLACKOUT, EMAT OVERLAY
Return the instrument to Tektronix for service.
-15 065-1043-XX 1 SERVICE REPLACEMENT KIT; 2CH FRONT CASE ASSY, 3 SERIES
MDO (PLASTIC AND LABELS)
Return the instrument to Tektronix for service.
065-1044-XX 1
SERVICE REPLACEMENT KIT; 4CH FRONT CASE ASSY, 3 SERIES
MDO (PLASTIC AND LABELS)
Return the instrument to Tektronix for service.
-16 366-0944-XX 2 KNOB, MEDIUM WITH OVERMOLD
-17 366-0943-XX 3 KNOB, SMALL WITH OVERMOLD
Table continued…
Replaceable parts
3 Series MDO Mixed Domain Oscilloscope Service Manual 31
