Turn On Time measurement: Configure panel.
Field or control Description
Input Source Selects the channel connected to the input side of the DUT.
Type Selects the input to output power conversion type. Default is DC-DC.
Label Sets the name of the measurement. You can use the default name, or double-tap in the field
and change the label using a connected keyboard or the virtual keyboard.
Maximum Voltage Sets the maximum input voltage, in the range of 1 V to 500 V.
Input Trigger Sets the input trigger level, in the range of 1 V to 500 V.
Frequency Sets the DUT input AC signal frequency, in the range of 1 Hz to 1 MHz.
Available when Type = AC-DC
Maximum Time Sets the maximum time window in which to capture the turn on time measurement (from the
initial state to a steady state), in the range of 1 μs to 500 s, with a resolution of 0.1 μs.
Number of Outputs (1, 2, 3, 4,
5, 6, or 7)
Sets the number of outputs to measure on the DUT (maximum of seven).
Output Source Selects the channel source to use for the listed output.
Output Voltage Sets the expected maximum voltage for each listed output, in the range of -6 kV to +6 kV, with a
resolution of 0.001 V. The measurement uses this value to set the vertical scale units for each
output waveform.
The instrument measures the actual maximum voltage on each output, and uses this value to
determine the output On/Off state levels, where On is ≥90% of the measured value, and Off is
≤10% of the measured value.
NOTE. The configuration value for maximum voltage and trigger level will not be remembered when it changes from AC-AC, AC-
DC, DC-AC, and DC-DC modes. It displays the default values.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 181
