Sequence
3. Cut is executed and the remaining data
in the sequence are shifted.
NOTE. Cut data
is placed in the clipboard.
Deleted data is removed from the sequence
and cannot be recovered.
4. Clear initializes the data of selected
waveform(s
) or element(s). A c leared
cell becomes Empty.
5. Use Inse
rt Waveform to insert a
waveform from the Waveform L ist.
6. You can use Paste-Insert or
Paste-Replace when you want to
set a wa
veform after copying any
waveform in the Sequence window.
AWG5000 and AWG7000 Series Quick Start User Manual 75
