Tektronix AWG7082C Quick Start Manual

Getting Acquain
ted with Your Instrument
Quick Tips
Trigger parameters control the signal outputs of the instrument. Trigger parameters cannot be set if Continuous is
selected in the Run Mode.
You can also control the trigger by pushing the front-panel Force Trigger button in addition to specifying a signal as
the trigger source.
Accessing Menus and Control Windows
You can access menu commands and control windows using the following techniques:
1. Click Settings from the menu bar, and
then selec
t a command.
The selected item in the Settings window
will become active.
2. For a shortcut to settings menus, you
can use the Settings window.
Clicking a tab, such as Ch 1 or Timing,
on the Settings window opens the
corresponding page that you can use to
select the instrument settings.
3. From the front panel, you can quickly
access the parameters for sampling rate,
amplitude level, offset level, and marker
level.
If you push one of these buttons, the
corresponding parameter in the Settings
window will be selected.
24 AWG5000 and AWG7000 Series Quick Start User Manual
