Data Input/Output
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
3- 249
Overview Control elements and resourcesTo save your setup (Cont.)
Name your
setup
5. Name your setup file by either:
H Accepting the default name (User) that appears in
the name field.
H Double-clicking in the name field and using the
keyboard window to enter a new name, replacing
the default file name.
Note. You can use the mouse or touch screen with the
virtual keyboard to type entries in the name field.
H Clicking the existing name and using an attached
keyboard to enter a new name.
To save to a file 6. To display the Save Instrument Setup As dialog, from
the Setup control window, touch Save.
The Save Instrument Setup dialog allows for the entry of
a file name, file type, and location.
Name a
destination
7. Use the Save in: drop-down list and buttons (see right)
to navigate to the directory in which to save your setup.
To Next Page
