Appendix A: Specifications
A-36
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Table A- 7: O/E converter (CSA7000 Series only) (Cont.)
Characteristic
2
Description
Smallest average power for mask test (sensiti vity),
typical
1310 nm and 1550 nm:
40 W peak-to-peak. 20 W (--17 dBm) average power assuming 50% average
duty cycle
780 nm and 850 nm:
80 W peak-to-peak. 40 W (--14 dBm) average power assuming 50% average
duty cycle
Assumes the scale factor is set to minimum W/div settings and signal is at
least 2 divisions peak-to-peak
Optical scale factor range 10 W per di vision to 500 W per division
Optical reference receiver typically available from the following scale factors:
1310 nm and 1550 nm:
13.5 W per division to 66 W per division
850 nm:
25 W per division to 125 W per division
780 nm:
28 W per division to 142 W per division
2
All specifications are with the O/E electrical out-to-CH1 input adapter installed.
Table A- 8: Data storage specifications
Characteristic Description
Nonvolatile memory retention time, typical ≥ 5 years
Nonvolatile memory, typical
TDS7104 & TDS7054
Up to two 50,000 point waveforms can be stored
Floppy disk Front-panel 3.5 in floppy disk drive, 1.44 MB capacity
Hard disk Rear-panel, removeable hard disk dri ve, ≥ 20 GB capacity
CD-RW or CD-ROM Rear-panel CD-RW or CD-ROM drive
Windows memory 512 MB
