Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-27
Table A- 4: Trigger specifications (Cont.)
Characteristic Description
Advanced trigger timer ranges Limits
Glitch type 1nsto1s
Runt type, time qualified 1nsto1s
Width type 1nsto1s
Timeout type 1nsto1s
Transition type 1nsto1s
Pattern type 1nsto1s
Setup/Hold type Setup and Hold timers Limits
Setup time (time from data transition to
clock edge)
--100 ns to +100 ns
Hold time (time from clock edge to data
transit ion)
--1 ns to +102 ns
Setup time + Hold time (algebraic sum of
the two settings)
+2 ns
n Advanced trigger timer accuracy For Glitch, Timeout, or Widt h types
Time range Accuracy
1 ns to 500 ns ±(20% of setting + 0.5 ns)
520 ns to 1 s ±(0.01% of setting + 100 ns)
Trigger level or threshold range
CSA7404, CSA7154, TDS7404,
TDS7254, TDS7154,
TDS6604, & TDS6404
Trigger Source Sensitivity
Any channel ±12 divisions from center of screen
Auxiliary input ±8V(±4.5 V for TDS6000 Series)
Line ±0 V, not settable
TDS7104 & TDS7054 Trigger Source Sensitivity
Any channel ±12 divisions from center of screen
Auxiliary input ±8V
Line ±400 V
