Appendix A: Specifications
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
A-39
Table A- 11: Environmental specifications (Cont.)
Characteristic Description
Humidity, operating 20% to 80% relative humidity with a maximum wet bulb temperature of +29 °C
(+84 °F) at or below +50 °C (+122 °F), noncondensing
Upper limit derated to 25% relative humidity at +50 °C (+122 °F)
Nonoperating With no diskette in floppy disk drive
5% to 90% relative humi dity with a maximum wet bulb temperature of +29 °C
(+84 °F) at or below +60 °C (+140 °F), noncondensing
Upper limit derated to 20% relative humidity at +60 °C (+140 °F)
Altitude, operating 3,048 m (10,000 ft.)
Nonoperating 12,190 m (40,000 ft.)
Random vibration, operating 0.22 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis, 3 axis, 30 minutes total,
with floppy disk and compact disk installed
Nonoperating 2.28 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis, 30 minutes total, 3 axis
Table A- 12: Certifications and compliances
Category Standards or description
EC Declaration of Conformity --
EMC
Meets intent of Directive 89/336/EEC for El ectromagnetic Compatibility. Compliance was
demonstrat ed to the following specifications as listed in the Offici al Journal of the European Union:
EN 61326 Emissions
1, 3
Class A Radiated and Conducted Emissions
EN 61326 Immunity
1
,
2
,
4
IEC 1000-4-2 Electrostatic Discharge Immunity
±4 kV contact discharge, ±8 kV air discharge,
performance criterion B
IEC 1000-4-3 RF field immunity
3V/m,80MHzto1GHz,
80% amplitude modulated with a 1 kHz sinewave
performance criterion A
IEC 1000-4-4 Electrical Fast Transient/Burst Immunity
1 kV on AC mains, 500 V on I/O cables, performance criterion B
IEC 1000-4-5 AC Surge Immunity
1 kV differential mode, 2 kV common mode,
performance criterion B
IEC 1000-4-6 RF Conducted Immunity
3 V, 150 kHz to 80 MHz, amplitude modulated with a
1 kHz sinewave, performance criterion A
IEC 1000-4-11 AC Mains Voltage Dips and Interruption Immunity
100% reduction for one cycle, performance criterion B
