Tektronix CSA7404 User Manual

Overview
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
3-3
Tasks or topics
Page no.ContentsSection titleSubtasks or subtopics
Signal Input Triggering waveforms Triggering Background on basic trigger operati on 3--71
Triggering Concepts Background on triggering concepts 3--72
Triggering From the Front
Panel
Using the front-panel edge trigger controls 3--78
Access Procedures Setting up t riggers with front-panel
controls
3--78
To Check Trigger Status Checking trigger status 3--82
Additional Trigger
Parameters
Using additional trigger controls 3--83
Advanced Triggering Overview and setup for triggering on
specific pulse and logic conditions
3--88
To Trigger on a Glitch Setting up glitch triggering 3--94
To Trigger on a Runt Pulse Setting up runt pulse triggering 3--96
Trigger Based on Pulse
Width
Setting up pulse width triggering 3--99
To Trigger Based on
Transition Time
Setting up transition time triggering 3--101
Trigger Based on Pulse
Timeout
Setting up pulse timeout triggering 3--104
Trigger on a Pat tern Setting up pattern triggering 3--105
To Trigger on a State Setting up state triggering 3--109
To Trigger on Setup/Hold
Time Violations
Setting up setup/hol d time violation
triggering
3--110
Sequential Triggering Overview and setup for triggering after
time delay and triggering on events
3--113
To Trigger on a Sequence Setting up triggering on a sequence 3--118
Comm Triggering
(optional on TDS7000
Series)
Overview and reference to documentation
on using communications triggering
3--122
Serial Pattern Triggering
(optional on TDS7000
Series)
Overview and reference to documentarian
on using serial pattern triggering
3--122
