Tektronix DPO71254C

Bus setups
Bus setup control window (Config tab)
From the Digital menu (or the Vertical menu), select Bus Setup.
Some instruments support serial data standards: SPI, I
2
C, USB, RS232, 8b10b, and MIPI. When you select a serial bus, the
instrument assigns specific bus signals (called components) to default digital channels and sets the threshold to an appropriate
voltage level.
Overview
Use the Bus Setup Control windows to define up to 16 buses from which to acquire, decode, and display data. You can set up
serial buses for the SPI, I
2
C, USB, RS232, 8b10b, and MIPI serial data standards. You can also set up clocked or unclocked
parallel buses.
NOTE. The instrument displays I2C as the IC (Inter-IC Bus) serial bus selection.
Buses are not available on DPO70000SX instruments.
For information on the controls, click the buttons.
■
Bus List
■
Display & Clear
■
Label
■
Position
■
I2C Bus
■
SPI Bus
■
RS232 Bus
■
USB Bus
■
MIPI CSI-2 Bus
■
MIPI DSI-1 Bus
■
8B10B Bus
■
PCIe Bus
■
CAN Bus
■
LIN Bus
■
FLEXRAY Bus
■
MIL-1553 Bus
■
Ethernet Bus
■
Custom Bus
■
Parallel Bus
■
Clocked Parallel Bus
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 107
