Recall a mask
Use the Mask Edit Setup control window to recall a mask.
1. From the Mask menu, select Mask Edit Setup.
2. In the Mask Edit control window, click the Recall button.
3. In the Recall dialog box, click User Mask; then select the mask you want to recall.
4. Click Recall to recall the mask.
NOTE. The default folder for saving masks is C:\Users\[Username]\Tektronix\TekScope\Masks. If you saved masks in a
different folder, click the Look in drop-down list to find the folder where your masks are saved.
Horizontal modes
From the Horiz /Acq menu, select Horizontal/Acquisition Setup; then open the Horizontal tab.
Overview. The instrument has three horizontal modes. The default mode is Automatic; the default record length limit is
200,000 points.
Oscilloscope reference
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 817
