The following programing commands are available for Link Training:

:LINKTRaining:STAte <OFF | ON> //Default: OFF

:LINKTRaining:ARMscope <OFF | ON> //Default: OFF

:LINKTRaining:STANdard <Ethernet_100G_KR4 | Ethernet_100G_CR4> //Default:

Ethernet_100G_KR4

:LINKTRaining:LANE1 <OFF | ON> //Default: ON

:LINKTRaining:LANE2 <OFF | ON> //Default: OFF

:LINKTRaining:LANE3 <OFF | ON> //Default: OFF

:LINKTRaining:LANE4 <OFF | ON> //Default: OFF

:LINKTRaining:MARK <FRAme | CONtrol | TRAining> //Default: FRAme

:LINKTRaining:TRIGgeron <FIRst_frame | LASt_frame | ALL_frames> //Default

ALL_frames

:LINKTRaining:ARMscope <OFF | ON> //Default: OFF

LinkTraining

216 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
