Commands Listed in Alphabetical Order
High or Low for t
he Noise At ļ¬eld in the Eye section of the Region tab in the
Measurement Setup dialog box. The Eye section is displayed only if you have an
eye-pattern or optical measurement deļ¬ned.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:NOISe {HIGH | LOW}
MEASUrement:MEAS<x>:NOISe?
Arguments
HIGH causes the measurement for noise to be taken at the high level of the
waveform.
LOW causes the measurement for noise to be taken at the low level of the
waveform.
Examples
MEASUREMENT:MEAS1:NOISE HIGH causes the noise measurement to be made
at the high level of the waveform for Measurement 1.
MEASUREMENT:MEAS2:NOISE? might return MEAS UREMENT:MEAS2:NOISE
LOW
, indicating tha t Measurement 2 will measure noise at the low level of the
waveform.
MEASUrement:MEAS<x>:REFLevel<x>? (Query Only)
This is a query only command that returns all reference level <x> settings for
measurement slot <x> (slot one through slot eight).
Group
Measurement
Syntax
MEASUrement:MEAS<x>:REFLev el<x>?
Examples
MEASUREMENT:MEAS1:REFLEVEL ? might return
MEASUREMENT:MEAS1:REFLEVEL 1:METHOD RELATIVE; ABSOLUTE:HIGH
0.00000000000E+000; LOW 0.00000000000E+000;MID
0.00000000000E+000; MEASUREMENT:MEA S1:REFLEVEL1:REL ATIVE:
HIGH 9. 00000000000E+001 ;LOW 1.00000000000E+001; MID
5.00000000000E+001
.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-229
