Commands Listed in Alphabetical Order

NOTE. The SOURC

E<x> SOURCE:<<x> argument speciﬁes the

source, which can be source 1 or source 2. To set the actual waveform

(channel, reference, or math) that is assigned to source, you must use the

MEASUrement:MEAS<x>:SOURCE<x> WFM command. Two sources are

provided because some measurements (gain, phase) require two sources.

Group

Measurement

Syntax

MEASUrement:MEAS<x>:SOUrce <x>:HILow:

TRACk:HIGH:ENABle { ON

|OFF|NR1}

MEASUrement:MEAS<x>:SOUrce <x>:HILow:TRACk:HIGH:ENABle?

Related Commands

MEASUrement:MEAS<x>:SOUrce<x>:HILow:METHod, MEASUrement:

MEAS<x>:SOUrce<x>:HILow:TRACk:LOW:ENABle

Arguments

ON enables tracking of the high value for the speciﬁed measurement on the

speciﬁed source waveform.

OFF disables tracking of the high value for the speciﬁed measurement on the

speciﬁed source waveform.

NR1 set to 0 disables tracking of the high value for the speciﬁed measurement

on the speciﬁed source waveform; any other value enables tracking of the

high value for the speciﬁed measurement on the speciﬁed source waveform.

Examples

MEASUREMENT:MEAS2:SOURCE1: HILOW:TRACK:HIGH:ENABLE O N enables

tracking of the high value used to take Measurement 2 on the Source 1 waveform.

MEASUREMENT:MEAS3:SOURCE2: HILOW:TRACK:HIGH:ENABLE? might return

MEASUREMENT:MEAS3:SOURCE2: HILOW:TRACK:HIGH:ENABLE 0, indicating

that the tracking of the high value for Measurement 3 on the Source 2 waveform

is disabled.

NOTE. A query always returns a 0 or 1.

MEASUrement:MEAS<x>:SOUrce<x>:HILow:TRACk:HIGH:VALue

This command sets or queries the high value used to calculate a speciﬁed

measurement on a speciﬁed source waveform. The measurement slot i s speciﬁed

by x, which c an be 1 through 8; the source is speciﬁed by x, which can be 1 or

2. Sending this command is equivalent to selecting a measurement slot (such as

Meas 3), selecting a source (such as Source1), turning tracking High off, and then

entering an absolute value in the High control box in the in the Hi/Low pane of the

DSA/CSA/TDS8X00/B Series Programmer Manual 2-245
