Commands Listed in Alphabetical Order
Group
Save and Recall
Syntax
SAVe:WAVEform {CH<x> | MATH<x> |
REF<x>}, {MAIn | MAG1 |
MAG2},{REF<x> | <filep ath>}
Related Commands
DELEte:WAVEform
Arguments
CH<x> selects a channel waveform to save. The range for x is 1 through 8.
MATH<x> selects a math waveform to save. The range for x is 1 through 8.
REF<x> selects a reference waveform to save. The range for x is 1 through
8. You can also use this argument as a destination into which a waveform
(including a reference waveform) can be saved.
MAIn selects Main as the timebase for the saved waveform. This is the default
timebase.
MAG1 selects MAG1 as the timebase for the saved waveform.
MAG2 selects MAG2 as the timebase for the saved waveform.
<file pat h> is the location to which the waveform will be saved.
The <file path> is a quoted string that defines the file name and path. Input the
file path using the form <drive>/<dir>/<filename>. The <filename> can be a
Windows long file name. Do not use wild card characters.
Examples
SAVE:WAVEFORM MATH2,MAIN,REF1 saves the Math 2 waveform displayed by
the Main timebase in Reference memory location 2.
SAVE:WAVEFORM MATH1,MAG1,"TEK00000.WFM" saves the Math1 waveform
and timebase to the file TEK00000.WFM in the default directory and on the
default drive.
SELect? (Query Only)
This is a query only command that returns the selected waveform that is affected
by the front-panel controls and the display status (on or off) of all waveforms.
Group
Vertical
Syntax
SELect?
2-274 DSA/CSA/TDS8X00/B Series Programmer Manual
