Commands Listed in Alphabetical Order
Group
Trigger
Syntax
TRIGger:CH<x>:CLKRec:VALu e { NONe | ENET1250 | ENET2500
| ENET3 125 | ENET9 953 | ENET10313 | ENET11 096 | FC1063 |
FC2125 | FC3188 | FC4250 | FC10519 | FEC2666 | FEC10664
| FEC10 709 | INFIn iband | INPUT_DATA | OC1 | OC3 | OC9 |
OC12 | OC18 | OC24 | OC36 | OC 48 | OC96 | OC192 | PCIX2500
| SATA1 500 | SATA3 000 | SATA6000 | SFEC125 00 | USEr |
VSR5_3318 | XAUI3125 | XAUI6250}
TRIGger:CH<x>:CLKRec:VALu e?
Related Commands
TRIGger:CH<x>:CLKRec:LIST?, TRIGger:CLKRec:SOUrce
Arguments
NONe disables clock recovery for t he specified channel.
ENET1250 selects clock recovery for the 1.250 Gb/s bit rate, in accordance
with the IEEE 802.3 standard.
ENET2500 selects clock recovery for the 2.500 Gb/s bit rate (2x Gigabit
Ethernet).
ENET3125 selects clock recovery for the 3.125 Gb/s bit rate, in accordance
with the IEEE 802.3ae-2002 standard.
ENET9953 selects c lock recovery for the 9.9533 Gb/s bit rate, in accordance
with the IEEE 802.3ae-2002 standard.
ENET10313 selects clock recovery for the 10.3125 Gb/s bit rate, in accordance
with the IEEE 802.3ae-2002 standard.
ENET11096 selects clock recovery for the 11.096 Gb/s bit rate, which
is a forward error-correction rate for 10GbE (10.3125 Gb/s per IEEE
802.3ae-2002).
FC1063 selec ts clock recovery for the 1.0625 Gb/s bit rate, in accordance
with the ANSI X3.230-1994 standard.
FC2125 selects clock recovery for the 2.125 Gb/s bit rate, in accordance with
the ANSI Fibre Channel Physical Interface (FC-PI) Rev 11 draft standard.
FC3188 selects clock recovery for the 3.1875 Gb/s bit rate, in accordance with
the proposed 10 Gigabit Fibre Channel (10GFC) standard.
FC4250 selects clock recovery for the 4.250 Gb/s bit rate, in accordance with
the ANSI Fibre Channel Physical Interface (FC-PI) Rev 11 draft standard.
FC10519 selects clock recovery for the 10.518750 Gb/s b it rate, in accordance
with the proposed 10 Gigabit Fibre Channel (10GFC) standard.
FEC2666 selects clock recovery for the 2.6660571 Gb/s b it rate, in accordance
with the ITU-T G.975 Recommendation.
2-306 DSA/CSA/TDS8X00/B Series Programmer Manual
