Commands Listed in Alphabetical Order
WFMOutpre:YM
Ult? (Query Only)
This is a query only command that returns the vertical scale factor in vertical units
per division of the waveform returned by the previous CURVe? command.
Group
Waveform Transfer
Syntax
WFMOutpre:YMUlt?
Related Commands
CH<x>:SCAle
Examples
WFMOUTPRE:YMULT? might return WFMOUTPRE:YMULT 0.100000000000,
indicating that the vertical scale of the previously transferred waveform was set to
100 mV pe
r division.
WFMOutpre:YOFf? (Query Only)
This is a query only command that returns the vertical position of the waveform
returned by the previous CURVe? command.
Group
Waveform Transfer
Syntax
WFMOutpre:YOFf?
Related Commands
CH<x>:POSition
Examples
WFMOUTPRE:YOFF? might return WFMOUTPRE:Y OFF 0, indicating that the
vertical position of the previously transferred waveform was at the centerline.
WFMOutpre:YSCALE? (Query Only)
Thisqueryonlycom
mand returns vertical unit scale factor of the incoming
waveform by the previous CURVe? command. The value in vertical units is
calculated by the following formula: Vertical Units = (Raw Data) x YSCALE +
YZERO.
NOTE. If the DATA:SOURCE is a math waveform, the WFMOUTPRE:YSCALE
value i s always 1. If the data source is a reference waveform, then the
WFMOUTPRE:YSC
ALE value depends on the original source data.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-371
