Status and Events
Table 3-5: Execution Error Messages (EXE Bit 4) (cont.)
Code Message
2546
Autoset error, Signal Amplitude too large
2547
Autoset error, Signal period not found
2548
Autoset error, Eye not found
2549
Autoset error, Phase R ef Clock too slow
2550 Application name error
2551
AutoSync error, No AutoSync on static wfm
2552
AutoSync error, No waveforms enabled
2553
AutoSync error, Mid Ref not found
2554
AutoSync error, Pattern Length not found
2555
AutoSync error, Data Rate not found
2556
AutoSync error, Trigger period not found
2557
AutoSync error, No AutoSync options selected
2558
AutoSync error, Trigger source is not PSync
2559
Autoset error, No TDR autoset on Ref w fm
2560
Autoset error, No TDR autoset on Math wfm
2561
Autoset e rror, Incident Edge not found
2562
Autoseterror,Reflection not found
2563
Autoset error, Selected Channel is not a TDR capable channel
Device Error
The following table lists the device errors that can occur during instrument
operation. These errors may indicate that the instrument needs repair.
Table 3-6: Device Error Messages (DDE Bit 3)
Code Message
300
Device-specificerror
310
System error
311 Memory error
312 PUD memory lost
313
Calibration memory lost
314
Save/recall memory lost
315
Configuration memory lost
316 RTL Hardware Error, severe problem
350
Queue overflow (does not set DDE bit)
System Event
The following table lists the system event messages. These messages are
generated whenever certain system conditions occur.
DSA/CSA/TDS8X00/B Series Programmer Manual 3-17
