Section 3: Instrument description Series 2600B System SourceMeter® instrument User's Manual
3-20 2600BS-900-01 Rev. A / August 2021
Setting source and compliance values
When the 2600B is in the edit mode (EDIT indicator is on), the editing controls are used to set source
and compliance values. Note that when you edit the source value, source autoranging is turned off
and remains off until you turn it on again.
To cancel source editing, press the EXIT (LOCAL) key.
To edit the source value:
1. Press the SRC key. The cursor flashes in the source value field.
2. Use the CURSOR keys (or turn the navigation wheel) to move the cursor to the digit that needs to
be changed.
3. Press the navigation wheel or the ENTER key to edit the source value. The EDIT indicator is
illuminated.
4. Change the source value (see Setting a value (on page 3-19)).
The +/- key toggles the polarity. The 0000 key sets the value to 0.
5. When finished, press the ENTER key (the EDIT indicator is not illuminated).
To edit compliance limit values:
1. Press the LIMIT key.
2. Select the type of compliance (CURRENT, VOLTAGE, or POWER).
3. Press the navigation wheel or the ENTER key to enter edit mode. The EDIT indicator
is illuminated.
4. Change the compliance value (see Setting a value (on page 3-19)).
5. When finished, press the ENTER key (the EDIT indicator is not illuminated).
The up and down range keys change the format of the limit value.
