To set the current limit in NORMAL output-off mode remotely:*
smuX.source.offlimiti = iValue
To set the voltage limit in NORMAL output-off mode remotely:*
smuX.source.offlimitv = vValue
* smuX can be smua for channel A or smub for channel B
Remote programming output-off states quick reference
The content of the following table is a quick reference of commands for programming output-off states
from a remote interface.
Output-off state programming quick reference
Command*
Description
smuX.source.offmode = smua.OUTPUT_NORMAL
Selects normal output-off mode.
smuX.source.offmode = smua.OUTPUT_HIGH_Z
Selects high-impedance output-off mode.
smuX.source.offmode = smua.OUTPUT_ZERO
Selects zero output-off mode.
smuX.source.offfunc = smua.OUTPUT_DCVOLTS
Sets 0 V output with current limit specified by
the smua.source.offlimiti attribute.
smuX.source.offfunc = smua.OUTPUT_DCAMPS
Sets 0 A output with voltage limit specified by
the smua.source.offlimitv attribute.
smuX.source.offlimiti = iValue
Sets current limit in normal output-off mode.
smuX.source.offlimitv = vValue
Sets voltage limit in normal output-off mode.
* smuX can be smua for channel A or smub for channel B
