To access the web interface:
1. Open a web browser on the host computer.
2. Enter the IP address of the instrument in the web browser address box. For example, if the
instrument IP address is 192.168.1.101, enter 192.168.1.101 in the browser address box.
3. Press Enter on the computer keyboard to open the web interface of the instrument.
If the web interface does not open in the browser, see LAN troubleshooting suggestions.
Web interface Welcome page
The Welcome page provides information about the instrument. It includes:
• The instrument model number, manufacturer, firmware revision number, and instrument serial
number.
• LXI information.
• LAN connection information.
• The TCP Raw Socket number and Telnet Port number.
• Instrument address strings.
• Calibration dates.
• The ID button, which helps you find the instrument if you have multiple instruments.
Figure 17: Web interface Welcome page
