Tektronix KEITHLEY SourceMeter 2600B Series User Manual

Series 2600B System SourceMeter® instrument User's Manual Section 4: Operation
2600BS-900-01 Rev. A / August 2021 4-7
The fundamental source-measure configurations for the 2600B are shown in the following figures.
When sourcing voltage, you can measure current or voltage, as shown in the following figure.
Figure 21: Fundamental source-measure configurations: Source V
A
Current meter
+
−
Voltage source
V
Voltage meter
When sourcing current, you can measure voltage or current, as shown in the following figure.
Figure 22: Fundamental source-measure configuration: Source I
A
Current meter
↑
Current source
V
Voltage meter
Refer to “Circuit configurations” in the Series 2600B Reference Manual for detailed information.
