Tektronix MDO3000 Series Technical Reference

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Offset rangeVolts/div
setting
1MΩ input 50 Ω and 75 Ω input
1 mV/div to
50 mV/div
±1 V ±1 V
50.5 mV /div
to
99.5 m V/div
±0.5 V ±0.5 V
100 mV/div
to
500 mV/div
±10 V ±5 V
505 mV/div
to
995 mV/div
±5 V ±5 V
1 V/div to
10 V/div
1
±100 V ±5 V
Offset ranges
NOTE. The input signal cannot exceed the maximum input voltage for the 50 Ω and 75 Ω input
paths. Refer to the Maximum input voltage specifications (earlier in this table) for more information.
Offset accuracy
(See page 83.)
±[0.005 X | offset - position | + DC Balance]
NOTE. Both the position and constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
50, RMS, unit in mV
Random noise,
sample acquisition mode,
50
 termination s etting
(See page 86.) MDO31xx MDO305x MDO303x MDO302x MDO301x
1 mV, Full BW 0.21 0.2 0.2 0.2 0.19
2
mV, Full BW
0
.33
0
.27
0
.25
0
.23
0
.21
5 mV, Full BW 0.5 0.36 0.36 0.3 0.3
10 mV, Full BW 0.7 0.5 0.5 0.45 0.45
20 mV, Full BW 1 0.9 0.9 0.9 0.9
50 mV, Full BW 3 2.75 2.75 2.75 2.25
100 mV, Full BW 4.5 4.15 4.15 4.15 4.15
200 mV, Full BW 9 8.15 8.15 8.15 8.15
500 mV, Full BW 20 20 20 20 20
1V,FullBW 40 40 40 40 40
MDO3000 Series S pecifications and Performance Verification 7
