Tektronix MDO3000 Series Technical Reference

Performance Ver
ification
Displayed Average Noise Level (DANL) with a TPA-N-PRE Preamp Attached
Table 32: Displayed Average Noise Level (DANL) with a TPA-N-PRE Preamp Attached
Displayed Average Noise Level (DANL) with a TPA-N-PRE Preamp Attached
Performance checks
Low limit Test resu lt High limit
9kHz-50kHz
N/A –117 dBm/Hz
50 kHz - 5 MHz
N/A –138 dBm/Hz
50 kHz - BW
(MDO3SA not
installed
)
N/A –148 dBm/Hz
5MHz-2GHz
(MDO3SA installed)
N/A –148 dBm/H
z
All models
2GHz-3GHz
(MDO3SA installed)
N/A –138 dBm/Hz
Auxiliary (Trigger) Output Tests
Table 3
3: Auxiliary (Trigger) Output Tests
Auxiliary (Trigger) Output Tests
Performance checks
Low lim
it
Test re
sult
High li
mit
High 1 M
 2.25
V
—
Low 1 M 
—
 0.7
V
High 50 
 0.9
V
—
Trigger Output
Low 50 
—
 0.
25 V
AF
G Sine and Ramp Frequency Accuracy Tests
Table34:AFGSineandRampFrequency Accuracy Tests
AF
G Sine and Ramp Frequency Accuracy
P
erformance checks
Low limit Test result High limit
Sine Wave at 10 kHz, 2.5 V,
50 
9.9987 kHz 10.0013 kHz
All models
Sine Wave at 50 MHz,
2.5 V, 50 
49.9975 MHz 50.0025 MHz
MDO3000 Series S pecifications and Performance Verification 65
