Specifications
Specification
s
This chapter contains specifications for the MDO3000 Series oscilloscopes. All specifications are guaranteed unless noted
as "typical." Typical specifications are provided for your convenience but are not guaranteed. Specifications that are marked
with the
symbol have associated procedures listed in the Performance Verification section.
All specifications apply to all MDO3000 models unless noted otherwise. To meet specifications, two conditions m ust
first be met:
The oscilloscope must have been operating continuously for twenty minutes within the operating temperature range
specified.
You must perform the Signal Path Compensation (SPC) operation described in this manual prior to evaluating
specifications. ( See page 71.) If the operating temperature changes by more than 10 °C (18 °F), you must perform
the SPC operation again.
Analog Channel Input And Vertical Specifications
Table 1: Analog channel input and vertical specifications
Characteristic Description
MDO3104, MDO3054, MDO3034, MDO3024,
MDO3014
4 analog, digitized simultaneously
Number of input channels
MDO3102, MDO3052, MDO3032, MDO3022,
MDO3012
2 analog, digitized simultaneously
Input coupling
DC, AC
Input termination selection
1M,50,or75.
The 75 setting is not available on MDO310X instruments.
Input termination,
1M, DC coupled
1M,±1%
MDO3000 Series S pecifications and Performance Verification 1
