Specifications
Table 3: Horizontal and acquisition system specifications (cont.)
Assumes that error due to aliasing is insignificant.
The term under the square-root sign is the stability, and is related to the TIE
(Time Int
erval Error). The errors from this term occur throughout a single-shot
measurement. The second term is a result of both the absolute center-frequency
accuracy and the center-frequency stability of the timebase, and varies between
multiple
single-shot measurements over the observation interval (the amount of time
from the first single-shot measurement to the final single-shot measurement).
12 MDO3000 Series Specifications and Performance Verification
