Tektronix MDO3000 Series Technical Reference

Specifications
Table 14: RF input specifications (cont.)
9kHz-50kHz
–117 dBm/Hz
50 kHz - 5 MHz
–138 dBm/Hz
50 kHz - BW (MDO3SA not
installed)
–148 dBm/Hz
5 MHz - 2 GHz (MDO3SA
installed)
–148 dBm/Hz
Displayed average noise level
(DANL) with T
PA-N-PRE Preamp
attached
2 G Hz - 3 GHz (MDO3S A
installed)
–138 dBm/Hz
Input vertical range Vertical Measurement range: +20 dBm to DANL.
Vertical setting of 1 dB/div to 20 dB/div in a 1-2-5 sequence.
Attenuation range
Attenuator Settings from 10 to 30 dB , in 5 dB steps
Spectrum trace length (points)
751 points
2nd h armonic distortion >100 MHz: < –55 dBc (< –60 dBc typical)
with auto settings on and signals 10 dB below reference level
2nd harm onic distortion: 9 kHz to 100 MHz: < –55 dBc (< –60 dBc typical)
with auto settings on, signals 10 dB below reference level, and reference level 
–5 dBm
3rd h armonic distortion >100 MHz: < –53 dBc (< –58 dBc typical)
with auto settings on and signals 10 dB below reference level
3rd harmonic distortion: 9 kHz to 100 MHz: < –55 dBc (< –60 dBc typical)
with auto settings on, signals 10 dB below reference level, and reference level 
–5 dBm
2nd order intermodulation distortion: >15 MH z: < –55 dBc (< –60 dBc typical)
with auto settings on and signals 10 dB below reference level
2nd order intermo du latio n disto rtio n: 9 kHz to 15 MHz : < –47 dBc (<
–52 dBc, typical)
with auto settings on, signals 10 dB below reference level, and reference level 
–5 dBm
3rd order intermodu lation distortion: > 15 MHz
< –55 dBc, (<–60 dBc, typical),
with auto settings on and signals 10 dB below reference level
Spurious response (SFDR)
3rd order intermodulation distortion: 9 kHz to 15 M Hz
< –55 dBc (<–60 dBc, typical),
with auto settings on and signals 1 0 dB below reference level and reference
level  –5 dBm
–45 dBc (-50 dBc typical) for side bands < 25 kHz offset from the carrier.
–55 dBc (–60 dBc typical) for side bands  25 kHz offset from the carrier
Residual spurious response
< –78 dBm
< -67 dBm at 2.5 GHz
< -76 dBm at 1.25 GHz
 –15 dBm reference level and RF input terminated with 50 
28 MDO3000 Series Specifications and Performance Verification
