Tektronix MDO3000 Series Technical Reference

Performance Ver
ification
Table 19: DC Balance (cont.)
Performance checks Vertical scale Low limit (div) Test result High limit (div)
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 1 DC Balance,
50 ,FullBW
1V/div
–0.200 0.200
1 mV/div
-0.5 mV 0.5 mV
2 mV/div
–0.500 0.500
10 mV/div
–0.250 –.250
100 mV/div
–0.200 0.200
Channel 1 DC Balance,
75 ,FullBW
1V/div
–0.200 0.200
1 mV/div
–0.300 0.300
2 mV/div
–0.200 0.200
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 1 DC Balance,
1M,FullBW
1V/div
–0.200 0.200
Channel 2
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 2 DC Balance,
50 ,20MHzBW
1V/div
–0.200 0.200
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 2 DC Balance,
75 ,20MHzBW
1V/div
–0.200 0.200
1 mV/div
–0.300 0.300
2 mV/div
–0.200 0.200
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 2 DC Balance,
1M,20MHzBW
1V/div
–0.200 0.200
MDO3000 Series S pecifications and Performance Verification 39
