Tektronix MDO3000 Series

Performance Ver
ification
Table 19: DC Balance (cont.)
Performance checks Vertical scale Low limit (div) Test result High limit (div)
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 4 DC Balance,
50 , 250 MHz BW
1V/div
–0.200 0.200
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 4 DC Balance,
75 , 250 MHz BW
1V/div
–0.200 0.200
1 mV/div
–0.300 0.300
2 mV/div
–0.2000 0.200
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 4 DC Balance,
1M, 250 MHz BW
1V/div
–0.200 0.200
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 4 DC Balance,
50 ,FullBW
1V/div
–0.200 0.200
1 mV/div
–0.500 0.500
2 mV/div
–0.250 0.250
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 4 DC Balance,
75 ,FullBW
1V/div
–0.200 0.200
1 mV/div
–0.300 0.300
2 mV/div
–0.200 0.200
10 mV/div
–0.200 0.200
100 mV/div
–0.200 0.200
Channel 4 DC Balance,
1M,FullBW
1V/div
–0.200 0.200
1
Channels 3 and 4 are only on four-channel oscilloscopes.
MDO3000 Series S pecifications and Performance Verification 43
