Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
DPO4PWR,
MDO3PWR
Power Analysis Application Module. Enables quick and accurate analysis of power quality, switching loss,
harmonics, safe operating area (SOA), modulation, ripple, and slew rate (dI/dt, dV/dt).
APPLication:TYPe
POWer:CURRENTSOurce
POWer:QUALi
ty:VCRESTfactor?
POWer:DISplay
POWer:GATESOurce
POWer:GATi
ng
POWer:HARMonics:DISplay:SELect
POWer:HARMonics:DISplay:TYPe
POWer:HAR
Monics:FREQRef
POWer:HARMonics:FREQR ef:FIXEDFREQ Value
POWer:HARMonics:IEC:CLAss
POWer:HA
RMonics:IEC:FILter
POWer:HARMonics:IEC:FUNDamental
POWer:HARMonics:IEC:GROUPing
POWer:H
ARMonics:IEC:INPUTPOWer
POWer:HARMonics:IEC:LINEFREQuency
POWer:HARMonics:IEC:OBSPERiod
POWer:H
ARMonics:IEC:POWERFACtor
POWer:HARMonics:MIL:FUNDamental:CALCmethod
POWer:HARMonics:MIL:FUNDamental:USER:CURrent
POWer:
HARMonics:MIL:LINEFREQuency
POWer:HARMonics:MIL:POWERLEVel
POWer:HARMonics:NR_HARMonics
POWer
:HARMonics:RESults:HAR<1-400>:FREQuency?
POWer:HARMonics:RESults:HAR<1-400>:IECMAX?
POWer:HARMonics:RESults:HAR<1-400>:LIMit?
POWer
:HARMonics:RESults:HAR<1-400>:PHASe?
POWer:HARMonics:RESults:HAR<1-400>:RMS:ABSolute?
POWer:HARMonics:RESults:HAR<1-400>:RMS:PERCent?
POWe
r:HARMonics:RESults:HAR<1-400>:TEST:IEC:CLASSALIMit?
POWer:HARMonics:RESults:HAR<1-400>:TEST:IEC:NORMAL?
POWer:HARMonics:RESults:HAR<1-400>:TEST:IEC:POHCLIMit?
POW
er:HARMonics:RESults:HAR<1-400>:TEST:MIL:NO RMAL?
POWer:HARMonics:RESults:IEC:FUNDamental?
POWer:HARMonics:RESults:IEC:HARM3ALTernate?
POW
er:HARMonics:RESults:IEC:HARM5ALTernate?
G-14 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
