Commands Listed in Alphabetical Order
BUS:B<x>:AUD
io:DATa:SIZe
Specifies the number of bits per word for the AUDIO bus.
NOTE. The number of bits specified for this command must be always
less than or
equal to the number of bits per channel (set using
BUS:B<x>:AUDio:CHANnel:SIZe).
Conditions
This command requires DPO4AUDIO application module for the
MDO4000/B
/C series, and MDO3AUDIO for MDO3000 series.
Group
Bus
Syntax
BUS:B<x>:AUDio:DATa:SIZe <NR1>
BUS:B<x>:AUDio:DATa:SIZe?
Arguments
NR1 specifies the number of bits per word.
Examples
BUS:B1:AUDIO:DATA:SIZE 8 sets the number of bits per word to 8.
BUS:B1:AUDIO:DATA:SIZE? might return :BUS:B1:AUDIO :DATA:SIZE 24
indicating that the number of bits per word is set to 24.
BUS:B<x>:AUDio:DATa:SOUrce
Specifies the data source waveform for the AUDIO bus.
Conditions
This command requires the DPO4AUDIO application module for the
MDO4000/B/C series, or the MDO3AUDIO for MDO3000 series.
Group
Bus
Syntax
BUS:B<x>:AUDio:DATa:SOUrce {CH1|CH2|CH3|CH4|
D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11| D12|D13|D14|D15}
BUS:B<x>:AUDio:DATa:SOUrce?
Arguments
CH1–CH4 specifies an analog channel as the data source waveform for the audio
bus.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-163
