Tektronix MDO3000 Series Program Manual

Commands Listed in Alphabetical Order
Examples
CALIBRATE:INT
ERNAL:START
initiates the internal signal path calibration of
the oscilloscope.
CALibrate:INTERNal:STATus? (Query O nly)
Returns the current status of the oscilloscope internal signal path calibration for
the last SPC operation.
NOTE. Disconnect or otherwise remove all input signals prior to starting
self-calibration. The self-calibration can take several minutes to complete .
Group
Calibration and Diagnostic
Syntax
CALibrate:INTERNal:STATus?
Related Commands
*CAL?
Returns
This query will return one of the following:
INIT indicates the oscilloscope has not had internal signal path calibration
run.
PASS indicates the signal path calibration completed successfully.
FAIL indicates the signal path calibrat
ion did not complete successfully.
RUNNING indicates the signal path calibration is currently running.
Examples
CAL:INTERN:STAT? might return :CALIBRATE:INTE RNAL:STATus INIT
indicating that the current status of the internal signal path calibrationisthatit
has not been run.
CALibrate:INTERNal:STATus:RF? (Query Only)
This query returns the status of the last SPC run for the RF portion of the
instrument: (doesn't include the analog channels). This query is synonymous
with
CALibrate:RESults:SPC:RF?
Group
Calibration and Diagnostic
Syntax
CALibrate:INTERNal:STATus:RF?
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-213
